AB-22x
  |
  |
  |
  |
| AB-220 | AB-221 | AB-222 | AB-223 |
Specification
| Case Type | Miditower |
| Chassis Material | Steel |
| Case Color | Black |
| Motherboard Support | mATX, ATX |
| Drive Bay: | |
| Ext. 5.25" | 1 for AB-222 2 for AB-221, AB-223 3 for AB-220 |
| Int. 5.25" | 1 for AB-220 2 for AB-221, AB-223 3 for AB-222 |
| Int. 3.25" | 7 |
| Int. 2.5" | 1 |
| Front I/O Ports | 2 x USB 2.0, 2 x 3.5mm Audio |
| Expansion Slots | 7 |
| Cooling System | |
| Front | 1 x 12 cm |
| Slide | 2 x 12 cm |
| Rear | 1 x 8 cm |
| PSU models | AB350, AB400, AB450, AB500, w/o PSU |
| Max. motherboard length, mm | 244 |
| Max. height of the CPU fan, mm | 135 |
| Max. PSU length, mm | 150 |
| Max. SVGA length, mm | 235 |
| Chassis dimensions (W x H x D), mm | 175 x 410 x 335 |
| Dimensions (W x H x D), mm | 195 x 410 x 380 |
| Net Weight w/o PSU / with PSU, kg | 2,5/3,5 |
| Optional accessories | HDD Adapters Front panel 3,5" Card Reader 3,5" Multifunction panel 5,25" |
| Model | w/o PSU | 350W | 400W | 450W | 500W | |
| AB-220 | P/N | EX247928 | EX247929 | EX247930 | EX247931 | EX247932 |
| EAN | 4897040858816 | 4897040858809 | 4897040858793 | 4897040858786 | 4897040858779 | |
| AB-221 | P/N | EX247933 | EX247934 | EX247935 | EX247936 | EX247937 |
| EAN | 4897040858762 | 4897040858755 | 4897040858748 | 4897040858731 | 4897040858724 | |
| AB-222 | P/N | EX247938 | EX247939 | EX247940 | EX247941 | EX247942 |
| EAN | 4897040858717 | 4897040858700 | 4897040858694 | 4897040858687 | 4897040858670 | |
| AB-223 | P/N | EX247943 | EX247944 | EX247945 | EX247946 | EX247947 |
| EAN | 4897040858663 | 4897040858656 | 4897040858649 | 4897040858632 | 4897040858625 |
