Series CB
CB-563 | CB-564 |
Specification
Case Type | Desktop Cube |
Motherboard Support | mini-ITX, mATX |
Chassis Material | Steel |
Drive Bay: | |
Int. 3.5" | 2 |
Int. 2.5" | 1 |
Front I/O Ports | 2 x USB 2.0, MIC & HD Audio |
LED indicators | 1 x Power, 1 x HDD, 1 x NIC |
Expansion Slots | 4 |
Cooling System | |
Front | 1 x 8 cm |
Rear | 2 x 8 cm |
Side | 2 x 12 cm |
PSU models | XP350, XP400, XP450, XP500, w/o PSU |
Water cooling support | Yes |
Max. motherboard length, mm | 244 |
Max. height of the CPU fan, mm | 105 |
Max. PSU length, mm | 160 |
Max. SVGA length, mm | 270 |
Case Color | Black |
Chassis Color | Black |
Chassis dimensions (W x H x D), mm | 222 x 290 x 280 |
Packing dimensions (W x H x D), mm | 228 x 305 x 323 |
Net Weight w/o PSU / with PSU, kg | 2,5/3 |
Optional accessories | HDD Adapters Front panel 3,5" Card Reader 3,5" |
Model | w/o PSU | 350 W | 400 W | 450 W | 500 W | |
CB-563 | P/N | EX254061 | EX254062 | EX254063 | EX254064 | EX254065 |
EAN | 4895205100367 | 4895205100220 | 4895205100237 | 4895205100244 | 4895205100374 | |
CB-564 | P/N | EX254056 | EX254057 | EX254058 | EX254059 | EX254060 |
EAN | 4895205100381 | 4895205100251 | 4895205100268 | 4895205100275 | 4895205100398 |
