Series EX

EX-401 EX-403 EX-405 EX-406
EX-401 EX-403 EX-405 EX-406



Specification

Case Type Miditower
Chassis Material Steel
Case Color Black
Motherboard Support mATX, ATX
Drive Bay:
Ext. 5.25" 1 for EX-406
2 for EX-401, EX-403
3 for EX-405
Int. 5.25" 1 for EX-405
2 for EX-401, EX-403
3 for EX-406
Int. 3.5" 3 for EX-405, EX-406
7 for EX-401, EX-403
Int. 2.5" 4 for EX-405, EX-406
Front I/O Ports 2xUSB 2.0, MIC & HD Audio
Expansion Slots 7
Cooling System
Front 1x12 cm
Rear 1x8 cm /1x9,2 cm for EX-401, EX-403
1x8 cm /1x9,2 cm /1x12 cm for EX-405, EX-406
Side 1x8 cm for EX-401, EX-403
2x12 cm for EX-405, EX-406
PSU models NPX450, NPX500, NPX600, w/o PSU
Max. motherboard length, mm 244
Max. height of the CPU fan, mm 145
Max. PSU length, mm 240
Max. SVGA length, mm 250 for EX-401, EX-403
400 for EX-405, EX-406
Chassis dimensions (W x H x D), mm 185 x 420 x 390
Dimensions (W x H x D), mm 205 x 420 x 425
Net Weight w/o PSU / with PSU, kg 3,3/4,3
Optional accessories HDD Adapters
Front panel 3,5"
Card Reader 3,5"
Multifunction panel 5,25"


Model   w/o PSU 450 W 500 W 600 W
EX-401 P/N EX203426 EX199445 EX199449 EX199441
EAN 4897040856751 4897040853477 4897040853484 4897040853491
EX-403 P/N EX203433 EX199450 EX199451 EX199443
EAN 4897040856775 4897040853538 4897040853545 4897040853552
EX-405 P/N EX244472 EX244458 EX244460 EX244462
EAN 4897040857819 4897040857826 4897040857833 4897040857840
EX-406 P/N EX244473 EX244459 EX244461 EX244463
EAN 4897040857857 4897040857864 4897040857871 4897040857888
