Type

TP-205 TP-206 TP-208 TP-302
TP-205 TP-206 TP-208 TP-302

Specification

Chassis Material Steel
Case Color Black/Silver
Motherboard Support mATX, ATX
Drive Bay:
Ext. 5.25" 3
Int. 5.25" 1
Ext. 3.5" 1
Int. 3.5" 2
Int. 2.5" 2
Front I/O Ports 2xUSB 2.0, MIC & HD Audio
Expansion Slots 7
Cooling System
Rear 1x8 cm/1x9,2 cm/1x12 cm
Side 1x8 cm
PSU models NPX400, NPX450, NPX500, w/o PSU
Max. motherboard length, mm 244
Max. height of the CPU fan, mm 145
Max. PSU length, mm 180
Max. SVGA length, mm 230
Chassis dimensions (W x H x D), mm 185 x 415 x 395
Dimensions (W x H x D), mm 185 x 415 x 430
Net Weight w/o PSU / with PSU, kg 3,3/4,3
Optional accessories HDD Adapters
Front panel 3,5"
Card Reader 3,5"
Multifunction panel 5,25"


Model   w/o PSU 400 W 450 W 500 W
TP-205 P/N EX201968 EX199372 EX199373 EX199454
EAN 4897040856720 4897040853590 4897040853606 4897040853613
TP-206 P/N EX201969 EX199455 EX199456 EX199457
EAN 4897040856737 4897040853620 4897040853637 4897040853644
TP-208 P/N EX254030 EX254031 EX254032 EX254033
EAN 4895205100497 4895205100077 4895205100084 4895205100091
TP-302 P/N EX201970 EX199458 EX199459 EX200007
EAN 4897040856744 4897040853651 4897040853668 4897040853989
