Pro 1U1062

1U1062

Specification

Motherboard Support mATX, ATX
Max. motherboard size, mm 305x244
Drive Bay:
Ext. 5.25" 1 (installed instead Int. 3.5" drive bay)
Int. 3.5" 3
Dust Front panel is equipped with dust filters
Front I/O Ports 2 x USB 2.0
Control & Indicator, LED 1 x Power, 6 x HDD, 1 x NIC
Switch POWER, RESET
Expansion Slots 1
Cooling System: 6 x 4 cm fans in the middle frame
PSU Support 1U Power Supply
Recommended Exegate PSU ServerPRO-1U-350ADS, ServerPRO-1U-400ADS, ServerPRO-1U-450ADS, ServerPRO-1U-500ADS, ServerPRO-1U-600ADS, w/o PSU
Chassis material 1.0 mm steel
Cases color Black
Chassis color Silver
Dimensions (W x H x D), mm 430x44x550
Packing dimensions (W x H x D), mm 560x140x680
Net Weight w/o PSU / with PSU, kg 6,5/8,1


PSU model w/o PSU 350W 400W 450W 500W 600W
P/N EX234950 EX237313 EX237314 EX237315 EX237316 EX237317
EAN 4897040856959 4897040857291 4897040857284 4897040857277 4897040857260 4897040857253
