Stabilizer AVR
AVR-750 | AVR-1200 | AVR-1600 | AVR-2500 |
Specification
Input Voltage, V | 140-260 |
Input Frequency, Hz | 50/60 |
Nominal Input Voltage, V | 220±10% |
Output Voltage, V | 140-260 |
Surge Energy Interference, J | 180 |
Protection | Against Overcharge, Overload, Surges, Lightning, and other power disturbances |
Indicator Mode | Green - Electric Network Mode, Yellow - Stabilization Mode, Red - Protiction Mode |
Environment | |
Operating Environment, °C | 0-40 |
Operating Relative Humidity, % | 0-95 |
Model | AVR-750 | AVR-1200 | AVR-1600 | AVR-2500 |
Socket | Socket CEE 7/3 x 2 | Socket CEE 7/3 x 4 | ||
Output power capacity VA/W | 750/280 | 1200/400 | 1600/800 | 2500/1200 |
Tripping Current, A | 5 | 7 | 10 | 14 |
Dimensions (L x W x H), mm | 115x135x110 | 175x175x150 | ||
Weight, kgs | 1,42 | 1,44 | 3,18 | 3,58 |
P/N | EP223636 | EP223637 | EP223639 | EP223640 |
EAN | 4897040856522 | 4897040856492 | 4897040856508 | 4897040856515 |
