Mi-xxxL

MI-205L MI-206L MI-212L MI-213L
MI-205L MI-206L MI-212L MI-213L

Specification

Case Type Slim Minitower
Chassis Material Steel
Case Color Black/Silver
PSU Type SFX
Motherboard Support mini ITX, mini DTX, mATX
Drive Bay:
Ext. 5.25" 1
Int. 3.5" 1
Front I/O Ports 2 x USB 2.0, MIC&HD Audio
Expansion Slots 4
Cooling System
Side 1 x 8 cm
PSU models ITX M300, M350, M400, M450, w/o PSU
Max. motherboard length, mm 244
Max. height of the CPU fan, mm 65
Max. PSU length, mm 100 (SFX)
Max. SVGA length, mm 255 (low profile )
Chassis dimensions (W x H x D) mm 94 x 285 x 385
Dimensions (W x H x D) mm 96 x 285 x 433 (without stands)
Net Weight w/o PSU / with PSU, kg 3,1/3,5
Optional accessories HDD Adapters
Front panel 3,5" for MI-212L, MI-213L
Card Reader 3,5" for MI-212L, MI-213L
Multifunction panel 5,25" for MI-212L, MI-213L


Model   w/o PSU 300 W 350 W 400 W 450 W
MI-205L P/N EX249495 EX249478 EX249479 EX249480 EX249481
EAN 4897040858984 4897040859158 4897040859141 4897040859134 4897040859127
MI-206L P/N EX249494 EX249482 EX249483 EX249484 EX249485
EAN 4897040858991 4897040859110 4897040859103 4897040859097 4897040859080
MI-212L P/N EX249496 EX249486 EX249487 EX249488 EX249489
EAN 4897040858977 4897040859073 4897040859066 4897040859059 4897040859042
MI-213L P/N EX249497 EX249490 EX249491 EX249492 EX249493
EAN 4897040858960 4897040859035 4897040859028 4897040859011 4897040859004
