Products / Archive / Case / MI-xxx

MI-xxx

MI-207 MI-208 MI-209
MI-207 MI-208 MI-209

Specification

Case Type Slim Minitower
Chassis Material Steel
Case Color Black/Silver
PSU Type SFX
Motherboard Support mini ITX, mini DTX, mATX
Drive Bay:
Ext. 5.25" 1
Int. 3.5" 1
Front I/O Ports 2 x USB 2.0, MIC&HD Audio
Expansion Slots 4
PSU models ITX M300, M350, M400, M450, w/o PSU
Max. motherboard length, mm 220
Max. height of the CPU fan, mm 65
Max. PSU length, mm 125 x 64 x 100 (SFX)
Max. SVGA length, mm 210 (low profile)
Chassis dimensions (W x H x D) mm 94 x 285 x 354
Dimensions (W x H x D) mm 96 x 285 x 377 (without stands)
Net Weight w/o PSU / with PSU, kg 2,8/3,2
Optional accessories HDD Adapters


Model   w/o PSU 300 W 350 W 400 W 450 W
MI-207 P/N EX268692 EX268688 EX268689 EX268690 EX268691
EAN 4895205104969 4895205104846 4895205104853 4895205104860 4895205104877
MI-208 P/N EX268697 EX268693 EX268694 EX268695 EX268696
EAN 4895205104976 4895205104884 4895205104891 4895205104907 4895205104914
MI-209 P/N EX268702 EX268698 EX268699 EX268700 EX268701
EAN 4895205104983 4895205104921 4895205104938 4895205104945 4895205104952
