Cable ExeGate UTP4-C5e-CU-S24-SW-OUT-PE-BK-305 UTP

Cable ExeGate UTP4-C5e-CU-S24-SW-OUT-PE-BK-305 UTP
Cable ExeGate UTP4-C5e-CU-S24-SW-OUT-PE-BK-305 UTP
Cable ExeGate UTP4-C5e-CU-S24-SW-OUT-PE-BK-305 UTP
Cable ExeGate UTP4-C5e-CU-S24-SW-OUT-PE-BK-305 UTP
Outside the premises. Construction of backbone and horizontal subsystems of structured cabling systems of category 5e in conditions of minor electromagnetic interference, moisture and UV radiation. It can be laid outside the walls of buildings and structures.

Transmission of 1 Gbit/s signals at a frequency of up to 100 MHz. with a speed of up to 1000 Mbit/s.

Specification

TypeUTP
AppointmentSuitable for outdoor use
Length, m305
Number of Pairs4
Wire Gauge, AWG24
ThreadsSolid
MaterialCU
ShieldingUnshielded (UTP)
CombustibilityNot LZSH
The presence of the cableYes
PackagingCoil
Jacket materialPE
ColorBlack
Conformity to standardsComply with 5 / Class D and ISO/IEC 11801, IEC 61156(2009), EN 50173, TIA/EIA 568-B. 2 standards
Max operating temperature, °C70
Min operating temperature, °C-35
Product size, cm26,5x32,8x33,5
Weight, kg1,686
P/NEX190974
EAN4897040852647
