1U550-04

1U550

Specification

Type 1U
Motherboard Support mini-ITX, mATX, ATX
Max. motherboard size, mm 244x305
Drive Bay:
Int. 3.5" 4
Int. 2.5" 6 or 8 if special adapter is used (opt.)
Front I/O Ports 2 x USB 2.0
Control & Indicator, LED 1 x Power, 1 x HDD, 1 x NIC
Switch POWER, RESET
Expansion Slots 1
Cooling System: 4 x 4 cm fans in the middle frame, 1 x 4 cm (opt.)
PSU 1U
Recommended ExeGate PSU ServerPRO-1U-250ADS, ServerPRO-1U-250DS, ServerPRO-1U-300ADS, ServerPRO-1U-300DS, ServerPRO-1U-350ADS, ServerPRO-1U-350DS, ServerPRO-1U-400ADS, ServerPRO-1U-450ADS, ServerPRO-1U-500ADS, ServerPRO-1U-600ADS
Chassis material 1.2 mm steel
Cases color Black
Chassis color Silver
Dimensions (D x W x H), mm 550 x 430 x 44
Net Weight w/o PSU / with PSU, kg 6,30/6,70


Model PSU P/N EAN
1U550-04 w/o PSU EX264265 4895205103375
1U550-04/250ADS 250 EX265494 4895205103887
1U550-04/250DS 250 EX265495 4895205103894
1U550-04/300ADS 300 EX265496 4895205103900
1U550-04/300DS 300 EX265502 4895205103917
1U550-04/350ADS 350 EX265497 4895205103924
1U550-04/350DS 350 EX265503 4895205103931
1U550-04/400ADS 400 EX265498 4895205103948
1U550-04/450ADS 450 EX265499 4895205103955
1U550-04/500ADS 500 EX265500 4895205103962
1U550-04/600ADS 600 EX265501 4895205103979
