2U390-04

2U390-04

Specification

Type 2U
Motherboard Support miniITX, mATX
Max. motherboard size, mm 244x244
Drive Bay:
Ext. 5.25" 2
Int. 3.5" 4
Dust Front panel is equipped with dust filters
Front I/O Ports 2 x USB 2.0
Control & Indicator, LED 1 x Power, 1 x HDD, 1 x NIC
Switch POWER, RESET
Expansion Slots 4
Cooling System: 2 x 8 cm fan
PSU ATX 8 cm fan
Recommended ExeGate PSU ServerPRO-500ADS, ServerPRO-600ADS, ServerPRO-700ADS, ServerPRO-800ADS
Chassis material 1.2 mm steel
Cases color Black
Chassis color Silver
Dimensions (D x W x H), mm 390 x 430 x 89
Net Weight w/o PSU / with PSU, kg 5/5,8


PSU w/o PSU 500W 600W 700W 800W
P/N EX264269 EX264958 EX264959 EX264960 EX264961
EAN 4895205103412 4895205104181 4895205104198 4895205104204 4897040857123
