2U420-06

2U420-06

Specification

Type 2U
Motherboard Support miniITX, mATX, ATX (together with 1U or 2U Power Supply)
Max. motherboard size, mm 305x244 (244x244 together with ATX Power Supply)
Drive Bay:
Ext. 5.25" 6
Int. 3.5" 3 (instead 3 x 3.5")
Dust Front panel is equipped with dust filters
Front I/O Ports 2 x USB 2.0
Control &Indicator, LED 1 x Power, 1 x HDD
Switch POWER, RESET
Expansion Slots 7 or 4 together wit ATX Power Supply
Cooling System: 2 x 8 cm fan
PSU 1U, 2U, ATX 8 cm fan
Recommended ExeGate PSU ServerPRO-1U-F250AS, ServerPRO-1U-F250S, ServerPRO-1U-F300AS, ServerPRO-1U-F300S, ServerPRO-1U-F350AS, ServerPRO-1U-F350S, ServerPRO-1U-F400AS, ServerPRO-1U-F400S, ServerPRO-500ADS, ServerPRO-600ADS, ServerPRO-700ADS, ServerPRO-800ADS
Chassis material 1.2 mm steel
Cases color Silver
Chassis color Silver
Dimensions chassis(D x W x H), mm 420 x 430 x 89
Dimensions (D x W x H), mm 452 x 482 x 89
Net Weight w/o PSU / with PSU, kg 6/7,3


PSU w/o PSU 500W 600W 700W 800W
P/N EX279419 EX279613 EX279614 EX279615 EX279616
EAN 4895205108905 4895205108912 4895205108929 4895205108936 4895205108943
