2U550-HS12

2U550-HS12

Specification

Type 2U
Motherboard Support ATX
Max. motherboard size, mm 305 x 244
Drive Bay:
Ext. 3.5" Hot Swap 12
Control & indicator, LED Power, HDD, 2 x NIC, Status LED
Switch POWER, RESET
Expansion Slots 7
3 x 8 cm (4with extra place 1 x 8 cm) in the middle frame
Recommended ExeGate PSU 1UFlex/1U
Max. height of the CPU fan, mm 65
Max. PSU length, mm 260
Max. PSU with opposite drive bay length, mm 100
Max. SVGA length, mm 260 (only using a low-profile SVGA)
Chassis material 1,2 steel
Cases color Silver
Chassis color Silver
Dimensions chassis (D x W x H), mm 550 x 431 x 89
Dimensions (D x W x H), mm 583 x 483 x 89
Net Weight w/o PSU / with PSU, kg 12,8 / 13,2


PSU, W w/o PSU 500 550 600 700 800
P/N EX281233 EX281294 EX281295 EX281296 EX281297 EX281298
EAN 4895205111967 4895205112056 4895205112063 4895205112070 4895205112087 4895205112094
