2U650-HS09

2U650-HS09

Specification

Type 2U
Motherboard Support ATX
Max. motherboard size, mm 305x244
Drive Bay:
Ext. 3.5" Hot Swap 9
Int.2.5" 1
Front I/O Ports 2 x USB 2.0
Control &indicator, LED 1 x Power, 1 x HDD
Switch POWER, RESET
Expansion Slots 7
Cooling System
Integral fan 4 x 80mm In the central part
Integral fan location In the central part
Fan Support 4 x 80 mm
Recommended ExeGate PSU 2U, TFX
Chassis material Steel
Metal thickness 1.2 mm
Cases color Black
Chassis color Silver
Dimensions chassis (D x W x H), mm 650 x 425 x 90
Dimensions (D x W x H), mm 700 x 485 x 90
Dimensions package (D x W x H), mm 820 x 580 x 200
Net Weight w/o PSU / with PSU, kg 13,3/14,4


PSU w/o PSU 500W 600W 800W
P/N EX284961 EX285223 EX285224 EX285225
EAN 4895205117969 4895205119895 4895205119901 4895205119918
