2U660-HS06

2U660-HS06

Specification

Type 2U
Motherboard Support microATX, ATX, SSI CEB, EATX
Max. motherboard size, mm 305x330
Drive Bay:
Int. 3.5" 2
3.5" HotSwap 6
Dust Front panel is equipped with dust filters
Front I/O Ports 2 x USB 2.0
Control & Indicator, LED 1 x Power, 1 x HDD, 1 x NIC
Switch POWER, RESET
Expansion Slots 7
Cooling System: 3 x 8 cm fan
PSU ATX
Recommended ExeGate PSU ServerPRO-500ADS, ServerPRO-600ADS, ServerPRO-700ADS, ServerPRO-800ADS
Chassis material 1.2 mm steel
Cases color Black
Chassis color Silver
Dimensions (D x W x H), mm 660 x 430 x 89
Net Weight w/o PSU / with PSU, kg 9,7/10,5


PSU w/o PSU 500W 600W 700W 800W
P/N EX264268 EX264954 EX264955 EX264956 EX264957
EAN 4895205103405 4895205104211 4895205104228 4895205104235 4895205104242
