4U300-08

4U300-08

Specification

Type 4U
Motherboard Support ATX
Max. motherboard size, mm 305 x 244
Drive Bay: á
Int. 3.5" 6 (8, if PSU length < 121mm)
Int. 2.5" 9 (8 instead 3.5 ")
Front I/O Ports 2 x USB 2.0
Controlá& indicator, LED Power, HDD
Switch POWER, RESET
Expansion Slots 7
Cooling System: 2 x 6 cm On the back panel (pre-installed)
Recommended ExeGate PSU ATX
Max. height of the CPU fan, mm 130
Max. PSU length, mm 165
Max. PSU with opposite drive bay length, mm 140
Max. SVGA length, mm 150 (240 by using a low-profile SVGA)
Max. SVGA length with HDD, mm 240 only by using a low-profile SVGA
Chassis material 1,14 steel
Cases color Silver
Chassis color Black
Dimensionsáchassis (D x W x H), mm 300 x 430 x 178
Dimensions (D x W x H), mm 335 x 483 x 178
Net Weight w/o PSU / with PSU, kg 6,45 / 6,9


PSU, W w/o PSU 500 600 700 800
P/N EX281235 EX281303 EX281304 EX281305 EX281306
EAN 4895205111981 4895205112148 4895205112155 4895205112162 4895205112179
