4U480-15/4U4132

4U4132

Specification

Type 4U
Motherboard Support mATX, ATX, SSI CEB, SSI EEB, EATX
Max. motherboard size, mm 305x330
Drive Bay:
Ext. 5.25" 1
Ext. 3.5" 1
Int. 3.5" 5
Dust Front panel is equipped with dust filters
Front I/O Ports 2 x USB 2.0
Control & Indicator, LED 1 x Power, 1 x HDD, 1 x SLEEP
Switch POWER, RESET
Expansion Slots 7
Cooling System: 2 x 8 cm on the rear panel
Place for add coolers: 1 x 12 cm on the front panel
PSU Support ATX Power Supply
Recommended Exegate PSU ServerPRO-500ADS, ServerPRO-600ADS, ServerPRO-700ADS, ServerPRO-800ADS
Chassis material 1.1 mm steel
Cases color Black
Chassis color Silver
Dimensions (D x W x H), mm 480 x 430 x 177
Net Weight w/o PSU / with PSU, kg 13,5/15,3


PSU model w/o PSU 500W 600W 700W 800W
P/N EX254720 EX244617 EX244611 EX244605 EX244587
EAN 4895205100657 4897040858571 4897040858526 4897040858472 4897040858427
