Series DCR

DCR-500D DCR-1000D DCR-1500D DCR-2000D
DCR-500D DCR-1000D DCR-1500D DCR-2000D

Specification

Features Microprocessor control
Input Frequency, Hz 50
Output Voltage, V 220±10%
Efficiency, % 98
Indicator Mode Working- Green LED
Delay - Yellow LED
Unusual - Red LED
Protection Against Overcharge, Overload, Surges, Lightning, and other power disturbances
Digital display of the input / output parameters Yes
Delay/Undelay selection Yes
Posission selection Yes
Circuit Protection Fuse
Operating Environment, °C 0-40
Operating Relative Humidity, % 0-95


Model DCR-500D DCR-1000D DCR-1500D DCR-2000D
Output power capacity VA/W 500/280 1000/600 1500/800 2000/1100
Input Voltage, V 150 - 260 140 - 260 140 - 260 140 - 260
Weight, kgs 2,4 4,2 5,6 6
Dimensions (L x W x H), mm 115 x 235 x 160 125 x 250 x 170 145 x 265 x 187 145 x 265 x 187
P/N EP259015 EP259016 EP259017 EP259018
EAN 4895205101937 4895205101920 4895205101913 4895205101906
