ExeGate HR series lead-acid maintenance-free batteries are manufactured using AGM technology. They have low internal resistance and self-discharge. Optimized for continuous charging or discharge-charge modes. Excellent discharge characteristics at short discharge times.

The battery case is made of ABS UL94-HB plastic, which does not support Gorenje. Fully sealed design that eliminates electrolyte leakage. Internal gas recombination system, no need to add water.

Specification

AppointmentFor UPS
Voltage, V12
Battery capacity, Ah9
Standards and certificationsDeclaration of conformity GOST 12.2.007.12-88;
GOST R IEC 61056-1-2012 Pn. 4.1.2 - 4.1.4, 4.4, 5.4, 5.7 - 5.10;
GOST R IEC 60896-22-2015 Clause 4.2,4.3,4.4
Battery Life
In buffered mode8 years (at 25°C)
Number of charge-discharge cycles in cyclic mode at 100% discharge260
Self-discharge3% per month at 20°C
Charge methodConstant voltage charge (25°C)
Cyclic mode2.35 - 2.4 V / cell
Buffer mode2.25 - 2.3 V / cell
Internal resistance of a fully charged battery (25°C), m?20
Cabinet materialABS plastic
Temperature modes
Storagefrom -35°C to + 60°C
Chargefrom -10°Cto + 60°C
Dischargefrom -20°C to + 60°C
Warranty12 months if operating conditions are observed
Terminal typeF2
Maximum discharge current (25 ° C)140A(5c)
Height with terminal, mm100
Delivery setBattery
Product size, mm151x65x94
Weight, kg2,52
P/NEP129860
EAN4897040852425
