Series i3

Optional accessories Accessories


Model i3 SEA
i3 SEA
i3 SEA LE
i3 SEA LE
Cases Features
Case TypeMinitowerMinitower
Motherboard Supportmicro ATX, mini ATX, ITXmicro ATX, mini ATX, ITX
Chassis MaterialSteelSteel
Material Thickness, mm0,40,45
Material of front panelGlass/plasticGlass
Material of left panelGlassGlass
Material of right panelSteelSteel
Screwless AccessYesYes
Number of screws for mounting the side panel, pcs66
Window on the side panelYesYes
LED BacklightMulticolor -n-adjustable fan lighting on the rear side-
Case ColorBlackBlack
Chassis ColorBlackBlack
Power
PSU TypeATXATX
Power supply locationIn the lower part of the rear sideIn the lower part of the rear side
PSU models*400NPX, 450NPX, 500NPX, 550NPX, 600NPX, 650NPX, 700NPX, 750NPX, 800NPX, 850NPX400NPX, 450NPX, 500NPX, 550NPX, 600NPX, 650NPX, 700NPX, 750NPX, 800NPX, 850NPX
Recommended ExeGate PSUSeries NPXSeries NPX
Construction
Internal 3,5" Drive Bay21 (1 instead 1 bottom fan)
Internal 2,5" Drive Bay3 (2 instead 2 internal 3.5")2 (1 instead 1 internal 3.5")
Dush Filter (location)On the top of the caseOn the top and bottom of the case
Expansion Slots44
Cooling System
Installed fans on the rear panel12 cm RGB x 1-
Places for installation on the top panel12 cm x 212/14 cm x 2
Places for installation on the rear panel12 cm x 1 (installed)12 cm x 1
Places to install on the side panel-12 cm x 2
Places for installation in the middle of the case12 cm x 212 cm x 2
Support Liquid Cooling SystemsYesYes
A place for water cooling on the top panel.YesYes
Recommended ExeGate fans12 cm12 cm
Interfaces
Interface locationAt the front panelAt the top
USB 2.0 Type-A21
USB 3.2 Gen1 Type-A11
Audio I/O PortsHD Audio 2 x 3.5mmHD Audio 2 x 3.5mm
Other parameters
Max. motherboard length, mm244244
Max. height of the CPU fan, mm162156
Max. PSU length, mm190180
Max. PSU length with drive opposite, mm160 with 3.5"HDD-
Max. SVGA length, mm245330
Chassis dimensions
Width, mm195200
Height, mm375380
Depth, mm285345
Case Dimensions
Width, mm195210
Height, mm386405
Depth, mm295350
Carton Dimensions
Width, mm245275
Height, mm350425
Depth, mm430450
Net Weight , kg2,683,55
Gross Weight , kg3,284,4
PSU models, PN/EAN
w/o PSUEX298221
4895205181120
EX299006
4895205185517
400W/NPXEX298749
4895205184824
EX299566
4895205190078
450W/NPXEX298750
4895205184831
EX299567
4895205190085
500W/NPXEX298751
4895205184848
EX299568
4895205190092
550W/NPXEX298752
4895205184855
EX299569
4895205190108
600W/NPXEX298753
4895205184862
EX299570
4895205190115
650W/NPXEX298754
4895205184879
EX299571
4895205190122
700W/NPXEX298755
4895205184886
EX299572
4895205190139
750W/NPXEX298756
4895205184893
EX299573
4895205190146
800W/NPXEX298757
4895205184909
EX299574
4895205190153
850W/NPXEX298758
4895205184916
EX299575
4895205190160
* At a customer's request Computer Cases can be completed with any PSU
