Power

ATX-600PPX ATX-700PPX ATX-800PPX ATX-850PPX
600PPX
Mining Edition
700PPX
Mining Edition
800PPX
Mining Edition
850PPX
Mining Edition

Specification

Features Intended for round the clock operation. Increased reliability due to the softened thermal conditions of keys and diodes.
Type ATX 12V v.2.3
PFC Active
AC input, V 110-240
Input current, A 8
Input Frequency Range, Hz 47-63
FAN, cm 14
Noise Level, dBA 25
Efficiency 81% typical load
Connectors:
20+4 pin ATX 1
4+4 pin CPU 1
2 for 800PPX, 850PPX
SATA 5
Molex 4
Floppy 1
6+2 pin PCI-E 2
Protection SCP, OVP, UVP, OCP, OPP/OLP, OTP
Quality Certificates CE, FCC, CV, UL, TUV, VSMI, CCC
MTVF, HRS 50000
Storage temperature, °C 0-40
Storage Humidity, % 20-90
Color Black
Dimension (W x H x D), mm 150x86x160
Weight, kg 1,9


Model 600PPX 700PPX 800PPX 850PPX
Max. Output Capacity, W 600 700 800 850
Input Voltage:
+3.3V, A 21 21 21 21
+5V, A 18 18 18 20
+12V1, A 30 35 40 42
+12V2, A 30 35 40 42
+5Vsb, A 3 3 3 3
-12V, A 0.3 0.3 0.3 0.3
Max Output Power:
+3.3V&+5V, W 120 120 120 120
+12V1&+12V2, W 540 636 726 760
-12V, W 3.6 3.6 3.6 3.6
+5Vsb, W 15 15 15 15
P/N EX270866 EX270867 EX270868 EX270869
EAN 4895205105683 4895205105690 4895205105706 4895205105713
