ModificationP/NEAN
w/o PSUEX2864294895205124073
350WEX2864384895205124080
400WEX2864394895205124097
450WEX2864404895205124103
500WEX2864414895205124110


Minitower ExeGate BA-309U2-AA350
Minitower ExeGate BA-309U2-AA350
Minitower ExeGate BA-309U2-AA350
Minitower ExeGate BA-309U2-AA350
Minitower ExeGate BA-309U2-AA350
Minitower ExeGate BA-309U2-AA350
Specification

Cases Features
Case TypeMiniTower
Motherboard SupportmATX
Chassis MaterialSteel
Material Thickness, mm0,5
Material of front and side panelsPlastic / Steel
Screwless AccessYes
Number of screws for mounting the side panel, pcs4
Case ColorBlack
Chassis ColorBlack
Power
PSU TypeATX
Power supply locationAt the top of the rear side
PSU modelsExeGate AA350
PSU, W350
Construction
External Drive Bay 5,25"1
External Drive Bay 3,5"1
Internal Drive Bay 3,5"3
Internal Drive Bay 2,5"3
Expansion Slots4
Cooling System
Places for installation on the front panel12 cm x 1
Places for installation on the rear panel8 cm x 1
Places to install on the side panel12 cm x 1
Interfaces
Interface locationIn the middle of the front panel
USB 2.0 Type-A1
USB 3.2 Gen1 Type-A2
Audio I/O PortsHD Audio 2 x 3.5mm
Other parameters
Max. motherboard length, mm244
Max. height of the CPU fan, mm135
Max. PSU length, mm200
Max. PSU length with drive opposite, mm180
Max. SVGA length, mm320
Max. SVGA length with drive opposite, mm310
Chassis dimensions
Width, mm170
Height, mm350
Depth, mm340
Case Dimensions
Width, mm190
Height, mm355
Depth, mm380
Carton Dimensions
Width, mm215
Height, mm400
Depth, mm440
Net Weight , kg2,85
