ModificationP/NEAN
w/o PSUEX2821794895205115118
400WEX2821814895205115033
450WEX2821824895205115040
500WEX2821834895205115057


Minitower ExeGate SP-135
Minitower ExeGate SP-135
Minitower ExeGate SP-135
Minitower ExeGate SP-135
Minitower ExeGate SP-135
Minitower ExeGate SP-135
Specification

Cases Features
ModelSP-135
Case TypeMiniTower
Motherboard SupportmATX
Chassis MaterialSteel
Material Thickness, mm0,7
Screwless AccessYes
Hinge For The LockYes
Case ColorBlack
Chassis ColorBlack
Power
PSU TypeATX
Power supply locationAt the top of the rear side
PSU modelsw/o PSU
PSU modelsUN400, UN450, UN500
Recommended ExeGate PSUSeries UN
Construction
External Drive Bay 5,25"1
External Drive Bay 3,5"1
Internal Drive Bay 3,5"4
Internal Drive Bay 2,5"2
Expansion Slots4
Cooling System
Places for installation on the rear panel8 cm x 1 or 9,2 cm x 1
Interfaces
Interface locationAt the top of the front panel
USB 2.0 Type-A2
Audio I/O Ports2 x 3.5mm
Other parameters
Max. motherboard length, mm240
Max. height of the CPU fan, mm135
Max. PSU length, mm240
Max. PSU length with drive opposite, mm210
Max. SVGA length, mm242
Max. SVGA length with drive opposite, mm210
Chassis dimensions
Width, mm175
Height, mm365
Depth, mm380
Case Dimensions
Width, mm175
Height, mm368
Depth, mm420
Carton Dimensions
Width, mm210
Height, mm410
Depth, mm460
Net Weight , kg4,6
