CPU Cooler

Model	EE97379	EE97379-PWM	EE97378	EE97378-PWM	EK-11508	EK-11508-PWM	ETA-20	ETA-20.PWM
Prototype	Intel E97379		Intel E97378		-
Cooler Material	Aluminum		Aluminum + copper		Aluminum
Supported Sockets	775/1150/1151/1155/1156/1200						1150/1151/1155/1156/1200/1366
Power Dissipation (TDP), W	65		95		75		100
Fan Dimension, mm	92 x 92 x 25
Fan Speed Control	-	PWM	-	PWM	-	PWM	-	PWM
Fan Speed, RPM	2400ą10%	1200-2600	2400ą10%	1200-2600	2200ą10%	1200-2600	2200±10%	1200-2600
Bearing type	Hydrodynamic
Power Connector Type	4 pin						3pin	4pin
Noise, dB	23	11-24	23	11-24	22	17-23.5	22	17-23,5
Fan Air Flow, CFM	48						50
MTBF, HRS	35 000
Rated Voltage, V	12
Input Current, A	0,22
Cable length, mm	250	280	250	280	250	280	280	280
Cooler Dimension, mm	95 x 95 x 60						105x98x85
Net Weight, g	189		198		189		198
Mounts	Push pins for simple and easy installation				Installation with screws
Thermal interface	Thermal grease applied to the base of the cooler				Thermal grease included
P/N	EX283280	EX283279	EX283278	EX283277	EX286138	EX286141	EX286142	EX286143
EAN	4895205116481	4895205116474	4895205116467	4895205116450	4895205123540	4895205123557	4895205123588	4895205123595

Model	EE80	EE80-PWM	EE90	EE90-Cu	EE90-PWM	EE90-PWM.Cu
Radiator material	Aluminum			Aluminum + copper	Aluminum	Aluminum + copper
Supported sockets	775/1150/1151/1155/1156/1200/AM2/AM2+/AM3/AM3+/AM4/FM1/FM2/754/939/940
Power dissipation (TDP), W	65	65	75	80	75	80
Fan size, mm	80x80x25		90x90x25
Fan type	CPU fan
Fan speed control	-	yes	-	-	yes	yes
Fan speed, rpm	2000	800-2400	2200		800-2400
Bearing type	Hydrodynamic
Power connector type	3pin	4pin	3pin	3pin	4pin	4pin
Noise level, dB	22	11-24	22	22	22	11-24
Maximum air flow, CFM	48	48	50	50	50	50
Service life, hours	35000
Rated voltage, V	12
Consumption current, A	0,22
Cable length, mm	200
Mountings	Equipped with multiple clips
Thermal interface	Thermal grease included
Product size, mm	119x119x67	119x119x67	119x119x67	122x122x68	119x119x67	122x122x68
Weight, g	205	205	215	265	215	265
P/N	EX286144	EX286145	EX286149	EX286151	EX286150	EX286152
EAN	4895205123489	4895205123496	4895205123502	4895205123519	4895205123526	4895205123533

Model	Wizard EE91-BLUE	Wizard EE91-RED	Wizard EE91-Cu.BLUE	Wizard EE91-PWM.BLUE	Wizard EE91-PWM.RED	Wizard EE91-PWM.Cu.BLUE	Wizard EXX200-PWM.BLUE	Wizard EXX400-PWM.RGB
Radiator material	Aluminum		Aluminum + copper	Aluminum		Aluminum + copper
Supported sockets	775/1150/1151/1155/1156/1200/AM2/AM2+/AM3/AM3+/AM4/FM1/FM2/754/939/940
Power dissipation (TDP), W	75		80	75		80
Fan size, mm	90x90x25							120x120x25
Fan type	CPU fan
Fan speed control	-			yes
Fan speed, rpm	2200			800-2400
Bearing type	Hydrodynamic
Power connector type	3pin			4pin
Noise level, dB	22			11-24
Maximum air flow, CFM	48						35	50
Service life, hours	35000
Rated voltage, V	12
Consumption current, A	0,22							0,36
Cable length, mm	200
Mountings	Equipped with multiple clips
Thermal interface	Thermal grease included
Backlight	Blue	Red	Blue		Red	Blue		RGB
Heat pipes	-						2	4
Product size, mm	119x119x67	119x119x67	122x122x68	119x119x67	119x119x67	122x122x68	115x135x85	128x155x80
Weight, g	215	215	265	215	215	265	330	680
P/N	EX286146	EX286147	EX286153	EX286148	EX286226	EX286154	EX286297	EX286159
EAN	4895205123632	4895205123670	4895205123649	4895205123656	4895205123717	4895205123663	4895205123779	4895205123687

Model	Dark Magic EE126A-RGB	Dark Magic EE126M-PWM.RGB	Dark Magic EE126R-PWM.RGB	Dark Magic EE126XL-PWM.RGB	Dark Magic EXX300B-PWM	Dark Magic EXX400B-PWM	Dark Magic EXX400B-PWM.RGB
Radiator material	Aluminum				Aluminum + copper
Supported sockets	775/1150/1151/1155/1156/1200/AM2/AM2+/AM3/AM3+/AM4/FM1/FM2/754/939/940
Power dissipation (TDP), W	100	100	95	125	125	140	140
Fan size, mm	120x120x25
Fan type	CPU fan
Fan speed control	-	yes
Fan speed, rpm	1800	900-2000			1200-2100
Bearing type	Hydrodynamic
Power connector type	4pin
Noise level, dB	18	11-24
Maximum air flow, CFM	50	40	50	54	50	50	50
Service life, hours	45000				35000
Rated voltage, V	12
Consumption current, A	0,22				0,36
Cable length, mm	200	300	300	200	200	200	200
Mountings	Equipped with multiple clips
Thermal interface	Thermal grease included
Backlight	RGB				-		RGB
Heat pipes	-			4	3	4	4
Product size, mm	130x130x95	125x125x75	130x130x95	125x125x90	135x122x165	135x122x165	135x122x165
Weight, g	410	410	410	410	560	595	595
P/N	EX286155	EX286156	EX286157	EX286158	EX286298	EX286299	EX286300
EAN	4895205123601	4895205123618	4895205123625	4895205123458	4895205123786	4895205123793	4895205123809
