3U330-02

3U330-02

Specification

Type 3U
Motherboard Support miniITX, mATX, ATX
Max. motherboard size, mm 244x305
Drive Bay:
Ext. 5.25" 1 (or 1 x 3.5")
Int. 3.5" 2
Int. 2.5" 2 (or 1 x 3.5")
Dust Front panel is equipped with dust filters
Front I/O Ports 2 x USB 2.0
Control &Indicator, LED 1 x Power, 1 x HDD
Switch POWER, RESET
Expansion Slots 4
Cooling System: 2 x 6 cm fan front, 2 x 6 cm side (opt.), 1 x 6 cm rear (opt.)
PSU ATX not exceed length140mm
Chassis material 1.2 mm steel
Cases color Black
Chassis color Silver
Dimensions chassis (D x W x H), mm 300 x 430 x 133
Dimensions (D x W x H), mm 340 x 482 x 133
Net Weight w/o PSU / with PSU, kg 5,3/6,15


PSU w/o PSU 500W 600W 700W 800W
P/N EX279706 EX279761 EX279762 EX279763 EX279764
EAN 4895205109001 4895205109018 4895205109025 4895205109032 4895205109049
